GTC-320R-01
Mounting : 3U Rack Mount
Construction : Aluminum
Color : Black
Drive Capacity : 1 x 2.5 Disk Hot Swap Bay, 2 x 3.5 Disk Hot Swap Bay (2.5 disk for 2ea is possible in option)
Slot : 7 Slot
Cooling : 2 x 92mm Cooling Fan, 2 x 50mm Cooling Fan
제품 상세정보
- Processor (CPU)
Intel® 8th/9th Generation Core i9/i7/i5/i3/Pentium®/Celeron® series Processor, Intel® Xeon®,
Intel® Xeon® E - 2100 Processor, Intel® Xeon® E-2200 Processor.
- System Memory
Up to 128GB Unbuffered ECC/Non-ECC UDIMM, DDR4 - 2666MHz, In 4 DIMM slots
- Network Controllers
Single LAN with Intel® Ethernet Controller I210 - AT Shared with IPMI
Single LAN with Intel® PHY I219LM LAN controller
- USB
2 USB 2.0 ports (2 via headers, Type A)
4 USB 3.1 Gen1 ports (2 Rears Type A, 2 via headers)
4 USB 3.1 Gen2 ports (1 Rears Type A + 1 Rear Type C, 1 via header, 1 Type A)
- Serial Port / Header
1 COM Port (1 header)
- Expansion Slots
1 PCI - 3.0 x 4 / 1 PCI - E 3.0 x 1 / 2 PCI - E x 16 slots are running at NA/16, or 8/8
1 x 5V PCI 32bit
- SMPS
M - ATX(SFX) 200W ~ 750W (80PLUS Standard / Bronze / Silver / Gold / Platinum / Titanium)
- Operating Environment
Operating Temperature Range - 0℃ ~ 50℃(32℉ ~ 122℉)
- OS Compability
Windows 10 Pro (32bit, 64bit) / Windows IOT Enterprise (32bit, 64bit)
- Dimensions (W x H x D)
16.9" (430mm) x 5.2" (132.7mm) x 19.3" (490mm)
