GTC-430R-01 > Customizing

- Processor (CPU)

  Intel® 8th/9th Generation Core i3/Pentium®/Celeron® series Processor, Intel® Xeon®,

  Intel® Xeon® E-2100 Processor, Intel® Xeon® E-2200 Processor.

- System Memory

  Up to 128GB Unbuffered ECC/Non-ECC UDIMM, DDR4-2666MHz, in 4 DIMM slots

- Network Controllers

  1 LANs with Intel® Ethernet Controller I210-AT Shared with IPMI

  1 LANs with Intel® Ethernet Controller I210-AT Shared with IPMI

- Expansion Slots

  3 PCI-E 3.0 x4 / 1 PCI-E x8 (in x16)

- SMPS

  400W 80Plus Bronze Level, 100-240 VAC, 50~60Hz

- Operating Environment

  Operating Temperature Range - 0°C ~ 50°C (32°F ~ 122°F)

- OS Compatibility

  Windows 10 Pro / Windows IOT Enterprise

- Dimensions (W x H x D)

  11.4" (290mm) x 5.5” (140mm) x 11.8" (300mm)​
