GTC-431F-01 > Customizing

- Processor (CPU)

  Intel® 8th/9th Generation Core i9/i7/i5/i3/Pentium®/Celeron® series Processor, Intel® Xeon®,

  Intel® Xeon® E-2100 Processor, Intel® Xeon® E-2200 Processor.

- System Memory

  Up to 64GB Unbuffered ECC/Non-ECC UDIMM, DDR4-2666MHz, in 4 DIMM slots

- Network Controllers

  1 LANs with Intel® PHY I219LM LAN controller

  1 LANs with Intel® Ethernet Controller I211-AT PCIe controller

- Expansion Slots

  3 PCI-E 3.0 x4 / 1 PCI-E x8 (in x16)

  1 PCI 32bit

- SMPS

  700W 80Plus Bronze Level, 100-240 VAC, 50~60Hz

- Operating Environment

  Operating Temperature Range - 0°C ~ 50°C (32°F ~ 122°F)

- OS Compatibility

  Windows 10 Pro / Windows IOT Enterprise

- Dimensions (W x H x D)

  12.6" (321mm) x 6.9" (176mm) x 16.5" (420mm)​
