GTC-K 4U Rev.2 > Customizing

- Specification



- Processor (CPU)

  Socket LGA 1200, support Intel® 10th Core i3 / i5 / i7 / Pentium Processors
  Xeon W-1200 Processors



- System Memory

  4 x Unbuffered ECC / non-ECC UDIMM DDR4-2933MHz slots, Up to 128GB



- Network Controllers

  1 x LAN with Intel® Ethernet i225V

  1 x LAN with Intel® PHY I219LM LAN controller, for AMT/vPro



- USB

  4 x USB 3.2 Ports (2 via header; 2 type A)

  5 x USB 3.2 Ports (3 rear type A; 1 rear type C; 1 via header)

  2 x USB 2.0 Ports (2 via header)



- Disk

  4 SATA3 RAID 0,1,5,10

  1 x M.2 22110, 2280, 22110 / M-Key / 2 PCIe 3.0 x4, RAID 0,1



- Expansion Slots

  1 x PCIe 3.0 x4

  2 x PCIe 3.0 x16 slots (16/NA or 8/8)

  1 x PCIe 3.0 x1

  1 x- 5V PCI 32bit



- SMPS

  Industrial 900W Single / 100-240Vac / 50-60Hz / 80Plus Gold Level



- Operating Environment

  Operating Temperature Range - 0°C ~ 50°C (32°F ~ 122°F)



- Dimensions

  427mm(W) x 177mm(H) x 360mm(D)
