PR-1500GW-R12 > Fanless Computer

 - Processor (CPU)

   LGA 1151 socket supports Intel® 6th/7th generation Core™ i7/i5/i3, Pentium® or Celeron® processor​

​ - System Memory

   Two 260-pin 1866/2133 MHz dual-channel DDR4 non-ECC unbuffered SO-DIMM

   ​Up to 32GB​

​ - Network Controllers

   LAN1: Intel® I219LM Clarkville-V with Intel® AMT 11.0 support

   ​LAN2: Intel® I211 PCIe controller

​ - Display

   1 x VGA (up to 1920x1200@60 Hz)

   ​1 x iDP interface for HDMI, LVDS, VGA, DVI, DP (up to 3840x2160@60 Hz)

​ - Graphics

   Intel® HD Graphics Gen 9 supports DX11/12, OpenCL 2.x and OpenGL 4.3/4.4

   ​Decode/Encode for HEVC, VP8, VP9, VDENC

​ - Storage

   ​2 x SATA :6Gb/s(RAID 0/1 support)

   ​​1 x mSATA :SATA & USB signal

​ - ​External I/O Interface

   ​​​2 x USB 3.2 Gen 1 (5Gb/s)

​ - ​Internal I/O Interface

   ​​​1 x KB/MS (1x6 pin) 2 x SATA 6Gb/s (RAID 0, 1 supported)

   ​​​1 x mSATA (SATA & USB signal) 4 x USB 2.0 (2x4 pin, P=2.0)

   ​​​2 x RS-232/422/485 (2x5 pin, P=2.0)

​ - Power Requirement

   5V@0.15A, 12V@8.39A, 3.3V@0.11A, 5VSB@0.21A

   ​(Intel® Core™ i7-6700K 4.0GHz with two 16 GB 2133 MHz DDR4 memory)

​ - Environment

   ​Operating Temp : -20 ~60℃ (-4 ~ 140℉​)

​ - Dimensions (W x H x D)

​     286mm x 132mm x 254mm
